JC-159Pneumatic Collar Type VFFS Machine
Collar forming with registration-mark control for printed film, up to 1 kg.
50 g – 1 kg28 – 30 pouches / min
The retail pouch machine. An adjustable volumetric dish sets the dose, and a centre (back) seal produces the familiar pillow pouch that kirana products, tea and detergent are sold in across India.
Centre-seal pouches from 50 g to 500 g for kirana, tea and detergent.
An adjustable volumetric dish sits at the top of the machine and is set to the pack weight. Because the dish is adjustable rather than a fixed cup, one machine covers 50 g through 500 g without buying a new dosing set for every SKU.
Every figure on this page is Packsol's published specification for the JC-155. Real output on your floor depends on your material's specific gravity and flow, your laminate and your fill size — which is exactly why we run a trial with your own product before quoting.
Adjustable dosing covers 50 g to 500 g, so a growing SKU range does not mean a growing machine list.
Centre seal is the format Indian retail expects for tea, kirana and detergent.
220V single phase — easy to install in a smaller unit.
A roll of suitable width is mounted at the rear of the machine and fed through the unwinding assembly, held at constant tension.
Film is drawn over the forming collar and down around the forming tube; the vertical sealer closes the back seam to make a continuous tube.
An adjustable volumetric dish sits at the top of the machine and is set to the pack weight. Because the dish is adjustable rather than a fixed cup, one machine covers 50 g through 500 g without buying a new dosing set for every SKU.
Horizontal sealing jaws close the bottom, then the top of the filled pouch. The cutting device separates each pouch automatically.
Sealed pouches drop onto the take-away chute or optional conveyor, ready for cartoning.
Published specification, exactly as Packsol states it. Check the electrical supply against what you have available before ordering.
| Model number | JC-155 |
|---|---|
| Application | Free-flowing Powder, Granules, Spices, Mehendi, Churn, Pharmaceutical Powder, Agricultural Powder, Ayurvedic Powder, Tea, Detergents, Chemicals, Kirana Items |
| Sealing type | Centre Sealing |
| Packing / filling range | 50 g, 100 g, 250 g and 500 g (depending on specific gravity of the material) |
| Speed | 25 – 28 pouches / min |
| Packing size | Length 100 – 280 mm · Width 200 – 400 mm |
| Packing material | All heat-sealable laminate — PET/POLY, PET/FOIL/POLY MET, PET/POLY/CPP/OPP etc. |
| Motor | ½ hp, 220V single phase, 50–60 Hz |
| Heater | 150W × 2 pcs + 400W × 2 pcs |
| Machine dimensions | 875 × 750 × 2200 mm |
| Net weight | 450 kg (gross 480 kg) |
| Optional equipment | Stainless steel cover, Gas flushing system, Product elevator, Batch printing unit, Conveyor |
Tell us your product and fill size — we'll quote properly.
Or call +91 99207 34394 · sales@packsolindustries.com
Products Packsol lists for this machine. If yours is not here, send us a sample — most materials behave like something on this list.
The manufacturer's own working drawing for this machine — useful when your maintenance team wants to see the layout before the machine arrives.
Need the full dimensional drawing or a foundation plan? Ask us on WhatsApp and we will send it across.
Post a sample with the fill weight and laminate, and we will trial it on the JC-155 at our Vasai works — so you see the finished pouch before you commit.
JC-159Collar forming with registration-mark control for printed film, up to 1 kg.
JC-150 Hover to playFree-flowing powder, granules and spice into 3 or 4 side-seal sachets from a single gram.
JC-157Volumetric dish counting for tablets, sugar-coated pills and chocolate balls.
Our machine selector matches your product, fill size and required output against all sixteen machines.
